------ English ------
Ø Qualcomm Multimode Chipset,, Support word mode network, TDD-LTE/FDD-LTE/UMTS/EDGE/GSM
Ø Low-power Energy and Powerful battery, endurance 30~35 hours, working all the day
Ø Built-in powerful 7800mAh Power Bank to charge smart phone or tablets
Ø Support Micro SIM(3FF SIM), Flexible selection operator.
Ø Up to 10 users access to WiFi.
Ø Size: 96*62*32
Ø Weight: 211g
|
Specification |
|
Platform |
||
|
CPU |
Qualcomm MDM9215 |
|
|
WiFi |
Qualcomm AR6302 ,2.4G, b/g/n |
|
|
Technical |
|
|
|
TD-LTE |
3GPP,3GPP2 Release9，Category 3,up to 68M DL and 17M bps UL |
|
|
FDD LTE |
3GPP,3GPP2 Release9，Category3,up to 100M DL and 50M bps UL |
|
|
DC-HPSA+ |
3GPP,3GPP2 Release8, up to 42Mbps ,category 24，5.76M bps UL |
|
|
HPSA+ |
3GPP,3GPP2 Release7, up to 14.4Mbps ,category 10，5.76M bps UL |
|
|
UMTS |
3GPP Release4, up to 384 Kbps DL and UL |
|
|
EDGE |
3GPP Release4, Multislot class 12, up to 237 Kbps |
|
|
Frequency Band |
|
|
|
TDD-LTE |
|
|
|
FDD-LTE |
B1(2100MHz), B3(1800MHz), B41(2600MHz) |
|
|
UMTS |
B1(2100MHz) |
|
|
TD-SCDMA NA |
NA |
|
|
GSM |
NA |
|
|
Interface |
|
|
|
LED |
Wifi Led, 4G Signal Led, Power led*3 |
|
|
Key |
Power/Reset/MENU |
|
|
SIM |
3FF(Micro SIM) |
|
|
Power bank |
YES |
|
|
Ethernet |
|
|
|
Battery |
Built-in 3.7V li-pol 7800mAh |
|
|
Charge |
Input 5V,2A，Output 5V,1A |
|
|
Environment |
|
|
|
Storage Temperature |
’-20˚C～75˚C |
|
|
Operator Temperature |
’-10˚C～45˚C |
|
