Form

USB Stick

Network Type

FDD WCDMA HSPA+  EDGE CDMA EVDO

CPU Speed

528MHz

Memory

DDR RAM：256MByte
EMMC FLASH ：1GByte

Transmission

FD-LTE 50Mbps/DL:100Mbps  HSPA+: 5.76mBbps/ DL 42Mbps
WCDMA : UL 384kbps/ DL 384kbps
GPRS/EDGE: Multi-slot Class 12

Frequency Scope

FDD B1 B3 B7 B20
WCDMA/HSPA+:
2100/900 MHz  OR 2100/850 MHz     (optional)
GSM/GPRS/EDGE: 850/ 900/ 1800/ 1900 MHz
CDMA 800M 1X
EVDO 800M REV B

Support System

32/64Bit: Win2000/XP/Vista/Win7/Android

Mac OS X 10.4 or later/LINUX

USIM/SIM

Standard 6 PIN SIM card interface

Drive

Zero-CD (No need CD-ROM)

Installation

No Installation Driver

Memory Extension

Support T-Flash memory extension, 32GB in max

Antenna

Built-in 3G&WIFI antenna

WIFI Antenna Gain: -2dbi

WIFI Antenna Sensitivity:
72M：-68dBm PER<8%                                                                                                 54M：-68dBm PER<8%
11M：-84dBm PER<8%

3G Antenna Gain: -2dbi

USB Version

Standard USB 2.0 high speed

Charging Mode

NA

Power Consumption

Input Voltage: 5V/1A

Output Voltage: 5V DC±10%

Max Power consumption: ＜3W

WiFi Standard

802.11b/g/n, speed upto 72Mbps

WiFi Frequency

2412MHz-2472MHz

WiFi Security Mode

Open, WPA-PSK, WPA2-PSK

Working Temperature

-10 to 55°C

Working Humidity

10%-85% RH

Storage Temperature

-20 to 70°C

Storage Humidity

5%-90% RH

Dimension/Weight

88mm*27mm*10.3mm/22g

Certificate

CE/RoHS
